Tip

0.65" Digital Micromirror Device (DLP™)

Çözünürlük

1920x1080 (1080p)

Lens

1.5× Manual optical zoom / Manual optical focus

Keystone

Dikey dijital keystone düzeltmesi: +/– 30 derece

Boyut

30"–300" / 0.76m–7.6m

Sunum Mesafesi

0.9m–10m / 3ft–32.8ft

Sunum Mesafe Oranı

1.4 – 2.14:1

Lamba

230 watt

Lamba ömrü (normal/eko mod)

4000 / 6000 hours

Parlaklık

2000 lumens

Kontrast Oranı

4000:1 (dynamic)

Görüntü Oranı

16:9 (native), 4:3, 16:10, Auto

Renk Gamutu

70% NTSC 1931 CIE

Bilgisayar ve Video

NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM (B, D, G, K, K1, L), SD 480i and 576i, ED 480p and 576p, HD 720p, 1080i and 1080p

Frekans

Fh: 31–91KHz, Fv: 48–85Hz

PC

VGA - 1080p

Mac®

Up to 1080p

Dijital

HDMI 1.3 (x2)

Kompozit Giriş

RCA jack

S-Video Giriş

4-pin mini-DIN

Kompanent

RCA (x3)

Kontrol

RS-232 (DB-9)

RGB (giriş/çıkış)

15-pin mini D-sub (x2) / 15-pin mini D-sub

Ses (giriş/çıkış)

3.5mm mini jack (x2), RCA (L/R) x1 / 3.5mm mini jack

USB

Type A for firmware update

Screen Trigger

3.5mm (12V/1A)

Hoparlör

10W (x2)

Voltaj

100~240VAC (Auto Switching), 50/60Hz (universal)

Tüketim

310W (max) / <1W (stand-by mode)

Basit

Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, enter, source

OSD

Picture: Color Mode, Brightness, Contrast, Video Setting, Color Setting, User Color, Gamma Video/Audio: Frequency, Tracking, H Position, V Position, Overscan, Noise Reduction, Audio Setting, Microphone Volume, Speaker Volume, Mute Setting: Auto Keystone, Keystone, Aspect Ratio, Projection, Auto Source, Signal Type, Eco-mode, Filter Mode, High Altitude, Quick Power ON, Quick Cooling, DC 12V Trigger Information: Input Source, Resolution, H Frequency, V Frequency, Filter Hours, Filter Hours Reset, Equivalent Lamp Hours, Equivalent Lamp Hours Reset, Factory Default Option: Blank Screen, Password, OSD Setting, Closed Caption, Others, Display Type, Swap, Function

Sıcaklık

32ºF–104ºF (0ºC–40ºC)

Nem

10%–90% (non-condensing)

Rakım

0~6,000 ft (1,800m), operational up to 10,000 ft (3048m)

Normal

31dB

Eco-mode

27dB

Fiziksel

13.1 × 4.3 × 10.4 (in) / 332.7× 110 × 264.2 (mm)

Kutu

16.3 × 14.8 × 7.5 (in) / 414 ×375.9 × 190.5 (mm)

Net

8.5 lb. (3.86 kg)

Brüt

11.8 lb. (5.36 kg)

CB, RoHS, SVHC, WEEE, UL/cUL, FCC-B, ICES-004, TUV-S (Argentina), NOM, PSB, C-tick, KC, CE, GOST-R, Hygienic, UKrSEPRO, CCC

ViewSonic projector, power cable, VGA cable, HDMI cable, remote control/laser with batteries, lens cap, Quick Start Guide, ViewSonic Wizard DVD (with User Guide)
