Tip

0.65" Digital Micromirror Device (DLP™)

Çözünürlük

WXGA 1280x800 (Native)

Lens

Fixed Lens / Manual Focus

Keystone

Boyut

30"–300" / .762m–7.62m

1.05ft–10.37ft / 0.32m–3.16m

0.5:1

Lamba

210 watt

4000 / 6000 hours

Parlaklık

3000 lumens

2000:1 static (typ); 3000:1 (dynamic)

16:10 (native), 16:9, 4:3, Auto

Renk Çemberi

6-Segment RGBCYW / 7200rpm

Renk Gamutu

99% NTSC 1931 CIE

Renk Derinliği

24 bits, 16.7M color (8+8+8)

Video

NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM (B, D, G, K, K1, L), SD 480i/576i, ED 480p/576p, HD 720p/1080i

Frekans

Fh: 31–100KHz, Fv: 48–120Hz

PC

VGA - UXGA

Mac®

Up to UXGA (scaled)

RGB Giriş

15-pin mini D-sub (x2)

Kompozit Giriş

RCA jack

S-Video Giriş

4-pin mini-DIN

RGB Çıkış

15-pin mini D-sub

Kontrol

RS-232 (9-pin mini-DIN)/RJ-45

Ses(giriş/çıkış)

3.5mm mini jack (x1), RCA (L/R)x1 / 3.5mm mini jack

Mic-In

3.5mm mini jack

Ekran tetikleme

2mm/1A

USB

Type A: for PC-less slide show presentation - support JPEG, BMP, TIFF, PNG, GIF from USB flash drive, optional wireless USB adapter Mini-B: for direct presentation from PC (not Mac compatible), Mouse Control

Hoparlör

10W (x1)

Voltaj

100~240VAC (Auto Switching), 50/60Hz (universal)

Tüketim

296W (typ) / 1W (stand-by mode)

Basit

Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, auto, mode/enter, source

OSD

Display: Screen color, Aspect raito, Keystone, Position, Phase, H. Size, Zoom, 3D sync, 3D sync invert, Color Management Picture: Color Mode, Reference Mode, Brightness, Contrast, Color, Tint, Sharpness, Brilliant Color, Color Temp., Save Settings Source: Quick Auto Search, PointBlank System Setup (Basic): Language, Projector Position, Auto Power Off, Blank Timer, Panel Key lock, Splash Screen, Screen Capture, Message, LAN Control Settings, Standby Settings System Setup (Advanced): High Altitude Mode, DCR, Audio Settings, Menu Settings, Closed Caption, Lamp Settings, Presentation Timer, Security Setting, Reset

Sıcaklık

32ºF–104ºF (0ºC–40ºC)

Nem

10%–90% (non-condensing)

Rakım

0~6,000 ft. (1,829m), operational up to 10,000 ft. (3048m)

Normal

32dB

Eco-mode

27dB

Fiziksel

11.4" x 5.0" x 10.0" / 290mm x 126mm x 254mm

Kutu

15.0" x 8.3" x 15.4" / 380mm x 210mm x 392mm

Net

7.7 lb. (3.5 kg)

Brüt

12.1 lb. (5.5 kg)

CB, UL, cUL, FCC (including ICES-003), CE, UL-Argentina, NOM, TUV-GS, GOST-R, SASO, Ukraine, PSB, C-Tick, Korean-eK, CCC, Hygiene, WEEE, RoHS

ViewSonic projector, power cable, VGA cable, laser remote control with batteries, lens cap, Quick Start Guide, ViewSonic Wizard CD (with User Guide)
