Product Type: 2-Way Premium Ceiling Speaker (8Ω/100V)
Frequency Response (-6dB): 70Hz - 20kHz
Nominal Coverage (-6dB): 100° Conical
RMS Power: 40W (8Ω)
Peak Power: 80W (8Ω)
Nominal Impedance: 8Ω (Transformer bypass)
Sensitivity (1W, 1m): 90dB
Maximum SPL (calculated): 109dB
Transformer Taps 100V: 2.5W | 5W | 10W
Transformer Taps 70V: 1.25W | 2.5W | 5W
Low Frequency Driver: 5.25" Reinforced Polymer Cone Woofer
High Frequency Driver: 0.75" Pivoting (±10°) Titanium Dome Tweeter
Input Connectors: Gold Plated Binding Posts (8Ω) / Quick Release Connector (100V)
White Frameless Magnetic Grille (Paintable) | Detachable Logo
Dimensions (ØxD): 204mm x 78mm
Cutout Diameter: 179mm
Mounting Depth: 78mm
Wall / Ceiling Thickness: 3mm to 15mm
Net Weight: 1.2kg
